Weldy Leister HT series 1600 D

Product Description

he energy HT1600 D overlap welding kit from Weldy, a Leister brand, is affordable for craftsmen and DIYers who want to overlap weld thermoplastics such as PE, PP and PVC (vinyl). The kit consists of the following five items: Weldy energy HT1600 D heat gun, 40 mm wide slot nozzle (article no. 124.777), 20 mm wide slot nozzle (article no. 124.772), 40 mm pressure roller made of silicone (article no. 130.611) and spare carbon brushes for the blower motor (article no. 125.810).

The Weldy HT 1600 heat gun has an LCD display that provides continuous digital temperature control from 40C (104F) to 620C (1,148F). The main applications for the energy HT1600 D overlap welding kit are overlap welding roofing membranes, shrinking foils, as well as welding floor coverings. Additionally, its used to dry and activate adhesives and fillers, shrink car wraps, as well as the process sensitive materials like leather and imitation leather (e.g. car interior).

Technical Data

MetricImperial

Article

160.174

Voltage

230 V

Frequency

50/60 Hz

Power

1600 W

Temperature

40 - 620 C

Temperature setting stepless

Yes

Airflow (20C)

120 - 240 l/min

Stepless air volume adjustment

Yes

Static pressure

2600 Pa

Eco-Mode

No

Display

Yes

e-Drive

Yes

Outdoor use

Yes

Nozzle connection

31.5 mm / 1.25 in

Length

360 mm

Device diameter

101 mm

Handle diameter

59 mm

Weight

1.2 kg

Power cable length

3 m

Plug

UK, 3 poles, 13A

Noise emission level

67 dB (A)

Approvals

CE

Protection class

II

Country of origin

P.R. China

Scope of delivery

130.611 Pressure roller 40 mm, silicone; 125.810 Carbon brushes; 124.777 Wide slot nozzle ( 31.5) 40 x 2 mm; 124.772 Wide slot nozzle ( 31.5) 20 x 2 mm

Precision Heating & Control

The HT Series 1600 D allows users to finely tune the heat output and airflow with its digital LCD display and stepless variable speed setting. Its temperature can be set anywhere from 80C to 650C, making it adaptable to a wide range of industrial applications, from welding plastics to shrink fitting and forming.


Durability and Easy Maintenance

Constructed with high-grade plastic and metal components, this heat gun is built to withstand rigorous use. The replaceable heating element and protection tube not only extend the tools service life but also ensure that maintenance is straightforward, minimizing downtime on the job.


Safety, Comfort, and Versatility

Featuring overheat protection and ergonomic design, the HT Series 1600 D is engineered for operator safety and comfort. Its 3-meter cable increases working flexibility, while the included nozzle and accessories make it suitable for tasks in flooring, roofing, banners, tents, and plastic welding with efficient noise levels.
